BentoIO CMX1 IO-Carrier Board for Raspberry Pi Compute Module 5 + Low Profile Heatsink

99,00

Low profile IO-Carrier Board for Raspberry Pi CM5 with headsink

Lieferzeit: 1–2 business days (Germany)

Only 1 left in stock (can be backordered)

SKU: terioto-bentoio-cmx1-v1-set-1 Category: Tags: , , Brand:

Specification

  • IO Board for Raspberry Compute Module 5 lite / eMMC support (CM4 not supported)
  • Form factor 85 mm × 85 mm
  • Low profile 11 mm
  • Raspberry Standard 40-pin GPIO header
  • Raspberry Pi mounting holes
  • Gigabit Ethernet via daughter board
  • HDMI via daughter board
  • MIPI DSI FPC connectors (22-pin 0.5 mm pitch)
  • USB 3 sockets
  • 2 x USB 2 internal sockets (PH2.0)
  • microSD card socket for CM5 Lite modules
  • M.2 M key PCIe socket (2230 / 2242)
  • RTC battery connector
  • Fan connector (4-pin)
  • USB-C Power Supply +5V
  • Power button on / off
  • Switch for flash mode

Contents

  • terioto CMX1 IO board
  • terioto CMX1 Low Profile Heatsink

Support

documentation-bentoio-cmx1-io-carrier-board

Weight 0,045 g
Dimensions 8,5 × 8,5 × 1,1 mm
